Dimensions
Folded:
168×83×49 mm (L×W×H)
Unfolded:
168×184×64 mm (L×W×H)
Max Ascent Speed
3 m/s (S - mode[1])
2 m/s (P - mode)
2 m/s (Wi-Fi mode)
Max Descent Speed
2 m/s (S - mode[1])
1.5 m/s (P - mode)
1 m/s (Wi-Fi mode)
Max Speed (near sea level, no wind)
68.4 kph (S - mode[1])
28.8 kph (P - mode)
28.8 kph (Wi-Fi mode)
Max Service Ceiling Above Sea Level
5000 m
Max Flight Time (no wind)
21 minutes (at a consistent 25 kph)
Max Hovering Time (no wind)
20 minutes
Max Flight Distance (no wind)
10 km (at a consistent 25 kph)
Max Wind Speed Resistance
29 - 38 kph
Max Tilt Angle
35° (S - mode[1])
25° (P - mode)
Max Angular Velocity
250°/s (S - mode[1])
250°/s (P - mode)
Operating Temperature Range
0°C - 40°C
Operating Frequency
2.400 - 2.4835 GHz
5.725 - 5.850 GHz
Transmission Power (EIRP)
2.400 - 2.4835 GHz
FCC: ≤28 dBm
CE: ≤19 dBm
SRRC: ≤19 dBm
MIC: ≤19 dBm
5.725 - 5.850 GHz
FCC: ≤31 dBm
CE: ≤14 dBm
SRRC: ≤27 dBm
Hovering Accuracy Range
Vertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GPS Positioning)
Horizontal:
±0.1 m (with Vision Positioning)
±1.5 m (with GPS Positioning)
Forward
Precision Measurement Range: 0.5 - 12 m
Detectable Range: 0.5 - 24 m
Effective Sensing Speed: ≤ 8 m/s
Field of View (FOV): Horizontal 50°, Vertical ±19°
Backward
Precision Measurement Range: 0.5 - 10 m
Detectable Range: 0.5 - 20 m
Effective Sensing Speed: ≤ 8 m/s
Field of View (FOV): Horizontal 50°, Vertical ±19°
Downward
Altitude Range: 0.1 - 8 m
Operating Range: 0.5 - 30 m
Operating Environment
Forward:
Surface with clear pattern and adequate lighting (lux > 15)
Backward:
Surface with clear pattern and adequate lighting (lux > 15)
Downward:
Detects clearly patterned surfaces with adequate lighting (lux>15) and diffuse reflectivity (>20%)
Operating Frequency
2.400 - 2.4835 GHz
5.725 - 5.850 GHz
Max Transmission Distance (unobstructed, free of interference)
2.400 - 2.4835 GHz:
FCC: 4000 m
CE: 2000 m
SRRC: 2000 m
MIC: 2000 m
5.725 - 5.850 GHz:
FCC: 4000 m
CE: 500 m
SRRC: 2500 m
Operating Temperature Range
0℃ - 40℃
Transmission Power (EIRP)
2.400 - 2.4835 GHz:
FCC:≤26 dBm
CE: ≤18 dBm
SRRC: ≤18 dBm
MIC:≤18 dBm
5.725 - 5.850 GHz:
FCC: ≤30 dBm
CE: ≤14 dBm
SRRC: ≤26 dBm
Operating Current/Voltage
1400 mA ⎓ 3.7 V (Android)
750 mA ⎓ 3.7 V (iOS)
Supported Mobile Device Size
Max length: 160 mm
Supported Thickness: 6.5-8.5 mm
Supported USB Port Types
Lightning, Micro USB (Type-B), USB-C
